Set 5G FR2 Antenna, directional, 24.25 to 29.5 GHz
Part number:3591/101
Includes:
› LNB Antenna, 24.25 to 29.5GHz, dir. (3591/01)
› Power Supply USB-C with cable
› LNB Antenna - Quick Start and Safety Instructions (3591/98.12)
Set 5G FR2 Antenna, omnidir., 24.25 to 29.5 GHz
Part number:3591/102
Includes:
› LNB Antenna, 24.25 to 29.5GHz, omn. (3591/02)
› Power Supply USB-C with cable
› LNB Antenna - Quick Start and Safety Instructions (3591/98.12)
Set 5G FR2 Antenna, dir. + omni., 24.25 to 29.5 GHz
Part number:3591/103
Includes:
› LNB Antenna, 24.25 to 29.5GHz, dir. (3591/01)
› LNB Antenna, 24.25 to 29.5GHz, omn. (3591/02)
› 2 x Power Supply USB-C with cable
› LNB Antenna - Quick Start and Safety Instructions (3591/98.12)
Antenna, Three-Axis, E-Field, 27 MHz – 3 GHz Part number : 3501/03
Antenna, Three-Axis, E-Field, 200 MHz – 6 GHz Part number : 3502/02
Antenna, Three-Axis, H-Field, 9 kHz – 250 MHz Part number : 3581/02
Antenna, Single-Axis, E-Field, 27 MHz – 3 GHz Part number : 3531/01
Antenna, Single-Axis, E-Field, 9 kHz – 300 MHz Part number : 3531/04
Antenna, Single-Axis, H-Field, 9 kHz – 300 MHz Part number : 3551/02
Options Description
Part number
Option, UMTS P-CPICH Demodulation
3701/04
Option, Scope
3701/05
Option, LTE (for FDD networks)
3701/06
Option, LTE (for TDD networks)
3701/07
Option, 5G NR
3701/08
Accessories Description
Part number
Antenna Holder for Uniaxial/Triaxial Antenna
3501/90.01
Antenna Holder for Triaxial Antenna
3501/90.02
RF-Cable, 9kHz-6GHz, 1.5m, N 50 Ohm (included in all sets)
3602/01
RF-Cable, 9kHz-6GHz, 5m, N 50 Ohm
3602/02
Tripod, Non-Conductive, 1.65 m with carrying bag
2244/90.31
Tripod Extension, 0.50m, Non-Conductive
2244/90.45
Battery Pack, Rechargeable, 7V2 / 6200 mAh (one is included in each SRM Basic Unit)
3001/90.15
Charger Set for Battery Pack, External
3001/90.07
Power Supply DC Vehicle Adapter
2260/90.56
SRM Hardcase Trolley (for up to three antennas), replaces 3001/90.05 and 3001/90.03
3006/90.01
Protective Soft Carrying Bag for SRM-3006 Basic Unit
3001/90.13
N-Connector Saver for SRM
3001/90.14
O/E Converter USB, RP-02/USB
2260/90.07
Cable, FO Duplex, F-SMA to RP-02, 0.3m
2260/91.01
Cable, FO Duplex, RP-02, 2m
2260/91.02
Cable, FO Duplex, RP-02, 5m
2260/91.09
Cable, FO Duplex, RP-02, 10m
2260/91.07
