車規靜電槍(ISO10605)

車規靜電槍-GT-30R3302KA
符合ISO10605第二版,包括以下所有測試配件
2K ohm testing discharge cup 03-00072A
CR unit 150pF-2k ohm 06-00074B
CR unit 330pF-2K ohm 06-00076B
330 ohm testing discharge cup 03-00071A
CR unit 150pF-330 ohm 06-00073B
CR unit 330pF-330 ohm 06-00075B
Discharge tip 12-00007A (Conical)
Discharge tip 12-00008A (Round)
Discharge tip 12-00009A (SphericalΦ30mm)
型號 : GT-30R3302KA


GT-30R3302KA (Set for 330 ohm and 2K ohm Tests to ISO 10605)

330 ohm testing discharge cup 03-00071A




Discharge tip 12-00007A (Conical)

Discharge tip 12-00007A

For contact discharge test

Compliance Standards:

IEC 61000-4-2 Ed1.2 & Ed2.0

ISO 10605 1st & 2nd Ed.




CR unit 150pF-330 ohm 06-00073B


CR Unit 06-00073A

Discharge tip 12-00008A (Round)

Discharge tip 12-00008A

For air discharge test

Compliance Standards:

IEC 61000-4-2 Ed1.2 & Ed2.0

ISO 10605 1st & 2nd Ed.

CR unit 330pF-330 ohm

06-00075B

CR unit 06-00075A

Discharge tip 12-00009A (SphericalΦ30mm)


Discharge tip 12-00009A
 For high voltage (over 15kV) air discharge

Compliance Standard:

ISO 10605 2nd Ed.

2Kohm testing discharge cup 03-00072A



CR unit 150pF-2k ohm 06-00074B

CR Unit 06-00073A

CR unit 330pF-2K ohm 06-00076A

CR unit 06-00075A



Instruction manual




ISO10605 車規靜電槍 GT-30R3302KA 包含以下配備:

GT-30R gun body

03-00071A gun head

03-00072A gun head

06-00073B 150pF-330 ohm CR unit

06-00074B 150pF-2K ohm CR unit

06-00075B 330pF-330 ohm CR unit

06-00076B 330pF-2K ohm CR unit

12-00007A conical tip

12-00008A round tip

12-00009A spherical tip
