| Parameters |
Specifications (Pulse 2b. 4) |
||
| Pulse 2b | UA, Us (*) | 0V ~ 60.0V ±10% ±0.5V in steps of 0.1V | |
| Ri | 0 ohm ~ 0.05 ohm | ||
| Td | 0.1s, 0.2s, 0.5s, 1s, 2s, 4s ±20% | ||
| t12, tr, t6 (*) | 1ms, 2ms, 5ms ±50% | ||
| Pulse 4 | Ub | 0V ~ 60V ±10% ±0.5V In steps of 0.1V | |
| Us, Ua | 0V ~ -Ub ±10% ±0.5V In steps of 0.1V | ||
| Ri | 0 ohm ~ 0.02 ohm (Factory setting) | ||
| t7, t8, t10, t11 (*) | 1ms ~ 999ms ±10% In steps of 1ms | ||
| t9 | 0.1s ~ 99.9s ±10% In steps of 0.1s | ||
| Dimensions |
(W) 430 X (H) 177 X (D) 550 mm (Projections excluded) |
||
| Weight | Approx. 26 kgs | ||
(*) Each item can be set separately.
Please contact us for details of 100A and 200A types.
|
|
