Narda FieldMan 用於進行精確測量以確保人身安全，特別是在可能出現高電場或磁場強度的工作環境中。 一項基本任務是證明符合一般安全法規，例如 FCC、IEEE、ICNIRP 或 EMF 指令 2013/35/EU。 測量環境的例子是：
› Radiocommunication base stations (e.g. IEC / EN 62232)
› Broadcasting systems (e.g. IEC 62577)
› Radar and satellite communications systems
› Induction heating and melting (e.g. EN 50519)
› Household appliances (e.g. IEC / EN 62233)
› Electric welding equipment (e.g. IEC / EN 62822)
› Railroad operations (e.g. EN 50500)
› Automotive operations (e.g. IEC 62764)
› Energy supply systems (e.g. IEC / EN 62110)
› Electrical medical devices (e.g. IEC / EN 60601)
› TEM cells and absorber chambers to demonstrate electromagnetic compatibility (EMC)
|
Digital Broadband Probes Description |
Part number |
|
Probe HFD-3061, H-Field, 300 kHz–30 MHz |
2462/05 |
|
Probe HFD-0191, H-Field, 27 MHz–1 GHz |
2462/06 |
|
Probe EFD-0391, E-Field, 100 kHz–3 GHz |
2462/01 |
|
Probe EFD-0392, E-Field, High Power, 100 kHz–3 GHz |
2462/12 |
|
Probe EFD-0691, E-Field, 100 kHz–6 GHz |
2462/14 |
|
Probe EFD-0692, E-Field, 600 MHz–6 GHz |
2462/20 |
|
Probe EFD-1891, E-Field, up to 18 GHz |
2462/02 |
|
Probe EFD-4091, E-Field, up to 40 GHz |
2462/19 |
|
Probe EFD-5091, E-Field, 300 MHz–50 GHz, Thermocouple |
2462/03 |
|
Probe EFD-6091, E-Field, 100 MHz–60 GHz |
2462/17 |
|
Probe EFD-9091, E-Field, 100 MHz–90 GHz |
2462/18 |
|
Probe EAD-5091, FCC 1997 Controlled, Shaped, 300 kHz–50 GHz, E-Field |
2462/07 |
|
Probe EBD-5091, IEEE 2019 Restricted, Shaped, 3 MHz–50 GHz, E-Field |
2462/21 |
|
Probe ECD-5091, SC 6 2015 Controlled, Shaped, 300 kHz–50 GHz, E-Field |
2462/16 |
|
Probe EDD-5091, ICNIRP 2020 Occ, Shaped, 300 kHz–50 GHz, E-Field |
2462/22 |
|
Digital Selective Probes Description |
Part number |
|
Probe BFD-400-1, B-Field, 100 cm2, 1 Hz–400 kHz, selective |
2463/01 |
|
Probe BFD-400-3, B-Field, 3 cm2, 1 Hz–400 kHz, selective |
2463/02 |
|
Field Analyzers Description |
Part number |
|
EHP-50F E&H Field Analyzer Set, 1 Hz–400 kHz (no Transport Case included) |
2404/105 |
|
EHP-50F E&H Field Analyzer Set, 1 Hz–400 kHz, Stand-alone/PC use |
2404/104 |
|
HP-01 Magnetometer Set DC–1 kHz |
2405/101
|
|
Options Description |
Part number |
|
Option, Narda-TSX Live Measurements, for FieldMan Digital Probes (expected from Q3 2023) |
2460/95.01 |
|
Option, GPS/ Range Finder for FieldMan |
2460/95.11 |
|
Option, WiFi/ Bluetooth for FieldMan (expected from Q4 2023) |
2460/95.12
|
|
Accessories Description |
Part number |
|
Digital Broadband Probe Repeater |
2464/01 |
|
Test-Generator 27 MHz |
2244/90.38 |
|
Tripod, Non-Conductive, 1.65 m, with Carrying Bag |
2244/90.31 |
|
Tripod, Benchtop, 0.16 m, Non-Conductive |
2244/90.32 |
|
Tripod Extension, 0.50 m, Non-Conductive (for 2244/90.31) |
2244/90.45 |
|
Handle, Non-Conductive, 0.42 m |
2250/92.02 |
|
Car Charger Adapter, USB-C PD |
2259/92.28 |
|
Cable, Digital Probe Extension, 2 m |
2460/90.02 |
|
Cable, Digital Probe to USB 2.0 (Type A), 3 m |
2460/90.03 |
|
Cable, FO Duplex (1000 μm) RP-02, 2 m |
2260/91.02 |
|
Cable, FO Duplex (1000 μm) RP-02, 5 m |
2260/91.09 |
|
Cable, FO Duplex (1000 μm) RP-02, 10 m |
2260/91.07 |
|
Cable, FO Duplex (1000 μm) RP-02, 20 m |
2260/91.03 |
|
Cable, FO Duplex (1000 μm) RP-02, 50 m |
2260/91.04 |
|
Cable, FO Duplex, F-SMA to RP-02, 0.3 m |
2260/91.01 |
|
O/E Converter RS232, RP-02/DB9 |
2260/90.06 |
|
O/E Converter USB, RP-02/USB |
2260/90.07 |
|
Cable, Adapter USB 2.0 - RS232, 0.8 m |
2260/90.53 |
