型號:GTEM 250
GTEM-Cell
Frequency range: 100kHz to 20GHz
Max. power input, W continuous/pulsed*:500*/1000
Dimensions: 1.27m x 0.64m x 0.44m (L x W x H)
Door size: 30cm x 23cm (WXH)
Max. EUT-Size: 20cm x 20cm x 15cm (L x W x H)
Size of uniform area (+/-3dB <1GHz): 15cm x 15cm x 10cm (L x W x H)
Septum height: 250mm
Input impedance: 50 ohms / Input connector N
Incl. feed-thru box equipped with:
1 pc. 2x6A power line filter incl 1 pc. socket (Schuko) inside
1 pc. fibre optical feed-thru (3 couple)
1 pc. coax-feed-thru, type N
2 pcs. coax-feed-thru, type SMA
Weight: ca. 30kg
型號:GTEM 400
GTEM-Cell
Frequency range: 100kHz to 20GHz
Max. power-input, W continuous/pulsed*:500*/1000
Dimensions:2.20m x1.22m x 0.83m (LxWxH)
Door size: 40cm x 40cm (WxH)
Max. EUT-Size: 35cm x 40cm x 25cm (LxBxH)
Size of uniform area (+/-3dB <1GHz): 25cm x 30cm x 13cm
(LxWxH)
Septum height: 400mm
Input impedance: 50 ohms / Input connector N
Incl. feed-thru box
1 pc. 2x10A power line filter incl 1 pc. socket (Schuko) inside
1 pc. fibre optical feed-thru (3 couple)
1 pc. coax-feed-thru, type N
2 pc. coax-feed-thru, type SMA
Weight: 120kg
Incl. wheeled undercarriage
型號:GTEM 750
GTEM-Cell
Frequency range: 100kHz to 20GHz
Max. power-input, W continuous/pulsed*:700*/1500
Dimensions: 4.0m x 2.20m x 1.50m (L x W x H)
Door size: 60cm x 60cm (W x H)
Max. EUT-Size: 60cm x 60cm x 50cm (L x W x H)
Size of uniform area (+/-3dB <1GHz): 45cm x 45cm x 25cm (L x W x
H)
Septum height: 750mm
Input impedance: 50 ohms / input connector N
Incl. feed-thru box
1 pc. 2x10A power line filter incl 1 pc. Socket (Schuko) inside
1 pc. fibre optical feed-thru (3 couple)
1 pc. coax-feed-thru, type N
2 pcs. coax-feed-thru, type SMA
2 pcs. unequipped technical panels
Incl. wheeled undercarriage
Weight: 400kg
