GTEM-400
GTEM-Cell
Frequency range: DC to 20GHz* Max. power input: 1kW / 2.5kW*
Dimensions:2.38m x1.22m x 0.83m (LxWxH)
Door size: 40cm x 40cm (WxH)
Max. EUT-Size: 35cm x 40cm x 20cm (LxBxH)
Size of uniform area (+/-6dB <1GHz): 13,5cm x 13,5cm x 13,5cm (LxWxH) Septum height: 400mm
Input impedance: 50 ohms / Input connector N
Incl. feed-thru box
1 pc. 16A power line filter 1 pc. 10A AC/DC filter 1 pc. fibre optical feed-thru (3 couple)
1 pc. coax-feed-thru, type N 2 pc. coax-feed-thru, type SMA
Weight: 250kg
